Stretch wrap film lines

An intelligent modular system to boost your productivity.

Dynamic markets are most reliant on rapid-fire solutions. That is why we opt for pre-engineered cast film lines in the stretch film segment, which we can optimise to fully suit your needs and your final product.
Our modular system allows for fast delivery and quick commissioning. Innovative engineering and the development of new core components, such as high-speed extruders and stretch film winders, help our customers to successfully position themselves in the highly competitive packaging industry.

Our technology.

It does not matter whether you need to work with small, compact lines or the largest of their kind in the world; whether you require final film widths from 1.5 to 6 metres or films whose layers number as few as 3 or as many as 67. Our stretch film machines can always produce the ideal wrapping film for every type of application.

After all, our special winders are one of the key components in every one of our stretch wrap film lines. There are three different winder models available depending on the requirements of the situation and the desired degree of automation.

Line Types

SML MiniCast stretch film line

Small, compact, strong.

MiniCast® stretch wrap film line



The SML MiniCast® stands out due to its compact design, taking up less than 100 sqm in floor space. It is typically equipped with four extruders creates an output up to 1,050 kg/h with up to 5 layers. The MiniCast® lines are prefabricated in small lots, meaning these stretch film lines are available at short notice. The MiniCast® is popular among both new market entrants and established manufacturers of niche products, impressing users with its high flexibility and ease of use.



Technical data
Productssuper power stretch, machine stretch, hand stretch, cling film, silage film
Film thickness range8 - 50 μm
Web width3 x 500 mm
Film structure3 or 5 layers
Production speedup to 650 m/min
Net output value
Film thickness range12 µm600 kg/h
17 µm845 kg/h
23 µm / MiniCast® 3L900 kg/h
23 µm / MiniCast® 5L1,050 kg/h

Unmissable benefits


  • Speedy delivery thanks to prefabricated components
  • Web width of 1.5 m allows roll widths of 3 x 500 mm or 2 x 750 mm
  • Ability to switch between 2” and 3” core diameter
  • Coreless
  • Modified edges
  • ThinCore technology





Winding technology that ensures perfect results.



We can always offer the ideal winder type which meets your needs. In the case of the MiniCast® stretch film line, our winder solutions are the winders W4000-2S and W4000-4S.
Click here to discover our complete range of winders.




SML EcoCompact stretch film line

Flexible, compact, efficient.

EcoCompact® stretch wrap film line

    Our EcoCompact® is a compact cast film extrusion line
    (floor space: 140 m²) that can produce top-quality stretch wrap film while providing maximum flexibility for fast product changes.

    This machine gives our customers efficient stretch film production capability with a film width of 2 m and an output rate of up to 1,600 kg/h. The EcoCompact® cast film line is particularly well-suited to medium-scale production runs.

      Technical data
      Productssuper power stretch wrap film, machine stretch, hand stretch, cling film
      Film thickness range8 - 50 μm
      Web width4 x 500 mm
      Film structure3, 5 or more layers
      Production speedup to 650 m/min
      Net output value
      Film thickness range12 µm800 kg/h
      17 µm1,125 kg/h
      23 µm1,200 kg/h
      SML EcoCompact stretch film line

      The benefits at a glance:


      • 4 x 500 mm or 5 x 400 mm wide rolls
      • Ability to switch between 2” and 3” core diameter
      • Coreless
      • Modified edges
      • ThinCore technology



      SML stretch film

      Winders that ensure perfect results.


      We can always offer the ideal winder type which meets your needs.
      In the case of the EcoCompact®, our winder solutions are the winders W4000-2S, W4000-4S and W3000-4S. Click here to discover our complete range of winders.

      SML SmartCast stretch film line

      Modular, flexible, powerful.

      SmartCast® stretch wrap film line

      The modular stretch film machine offers the perfect combination of high output and great flexibility.
      It is remarkable for its four pre-configured extruder groups (with output of between 1,900 and 3,000 kg/h) and the choice available between five, seven or more layers, enabling it to meet almost all customers’ requirements.



      One special highlight is its chill roll unit with positioning system. This makes the casting position 100 % reproducible, guaranteeing that all the process parameters can be repeated to perfection at all times.

        Technical data
        Productssuper power stretch, machine stretch, hand stretch, cling film
        Film thickness range8 - 50 μm
        Final web width6 x 500 mm
        Film structure5, 7 or more layers
        Production speedup to 750 m/min
        Net output value
        SmartCast®: Film thickness range12 µm1,400 kg/h
        SmartCast® XL: Film thickness range17 µm2,000 kg/h
        23 µm2,400 kg/h
        SML EXTRUDER

        Benefits that make SmartCast® the clear choice:

        • Film width of 3m allows 6 x 500 mm or 4 x 750 mm roll applications
        • Ability to switch between 2” and 3” core diameter
        • Coreless
        • Modified edges
        • ThinCore technology





        Winders that ensure perfect results.

        We can always offer the ideal winder type which meets your needs.
        In the case of the SmartCast®, our winder solutions are double turret winders W4000-2S and W4000-4S or the winder W3000-4S.
        Click here to discover our complete range of winders.

        SML PowerCast stretch film line

        Where high quantity meets top quality.

        PowerCast stretch wrap film line

        Our PowerCast® is an ultra-high-performance stretch film extrusion line that is perfectly suited to the market’s needs in terms of quality and quantity.
        Whether with 7 layers or 67, its output rate will be between 2,400 and 3,800 kg/h with three pre-configured extruder groups. These stretch wrap machines stand out due to their unrivalled flexibility in production and ability to handle film widths of 4 or 4.5 m. It was the first cast film line in the world featuring a chill roll unit which has a diameter of 1,600 mm. In short, the PowerCast® is engineered for perfect production results.

          Technical data
          Productssuper power stretch, machine stretch, hand stretch, cling film
          Film thickness range8 - 50 μm
          Final web width -
          PowerCast
          8 x 500 mm, 9 x 450 mm,
          10 x 400 mm
          Final web width -
          PowerCast XL
          6 x 750 mm, 9 x 500 mm,
          10 x 450 mm, 11 x 400 mm
          Film structure7 - 67 layers
          Production speedup to 850 m/min
          Net output value
          PowerCast12 µm> 2,000 kg/h
          23 µm3,400 kg/h

          Benefits only offered by a PowerCast®:


          • 4m stretch film machine allows for 4  x 1,000, 8 x 500, 9 x 450 or 10 x 400 mm roll applications
          • Modified edges
          • ThinCore technology

          Winding technology that ensure perfect results.


          We can always offer the ideal winder type which meets your needs.
          In the case of the PowerCast®, our winder solutions are the triple-turret winders W4000-2S and W4000-4S.
          Click here to discover our complete range of winders.

          SML MasterCast stretch film line

          In a production class of its own.

          MasterCast® stretch wrap film line

          SML is raising the bar in stretch wrap film production with its MasterCast®, the largest cast film extrusion line of its type, which stands out by virtue of its enormous output. The SML MasterCast® is unique in the world, with a width of 6 metres and an extrusion capacity of up to 5,000 kg/h.

          As a result, it can scale unprecedented heights in terms of investment cost per kilogram of output, reduced labour costs and optimum energy consumption, making it one of the world’s most efficient systems.





          Technical data
          Productssuper power stretch, machine stretch, hand stretch
          Film thickness range8 - 50 μm
          Final web width12 x 500 mm
          Film structure5 or 7 layers
          Production speedup to 650 m/min
          Net output value
          Film thickness range12 µm2,400 kg/h
          17 µm3,300 kg/h
          23 µm4,000 kg/h
          SML stretch film line, MasterCast

          Benefits as unique as the MasterCast® stretch film line itself:


          • 6 m film web width
          • 5 and 7-layer versions
          • Output of up to 5,000 kg/h

          Winding technology that ensures perfect results.



          We can always offer the ideal winder type which meet your needs. In the case of the MasterCast®, the solution are our fully automatic triple-turret winders W4000-2S and W4000-4S.
          Click here to discover our complete range of winders.
